HPL | Techno
40A Single Pole B Curve MCB - Grey TSPB40Price-On Request
Handling Charge : ₹ 0.00
ISI / CE Marked as per IS/IEC 60898 -1
Degree of Protection - IP 20
Connecting Terminals - 25 sq. mm
Breaking Capacity - 10kA
Mid Trip technology
Energy Limiting Class - Class 3
Rated Frequencies - 50/60Hz
Operating Voltage - 240V / 415V AC
Insulation Voltage - 660V
Planning to Build?
Let's build a home that speaks to your needs, it's yours to demand
Refer & Earn
Refer anyone looking to construct a home and earn up to ₹15,000 when they sign with us*
Additional Information
| Brand | HPL |
|---|---|
| Model Name | Techno |
| Material | PBT/Nylon |
| Colour | Grey |
| Warranty | N/A |
| Module Size | 1 |
| Tripping Characteristics | B Curve |
| Type | MCB |
| Class | Budget |
| Current Rating (A) | 40A |
| Voltage Rating (V) | 240/415V |
| Number of Poles | Single Pole |
| Protection Class | - |
